ENGINEERING THE HEIGHT OF REFINERY PERFORMANCE,
RAS TANURA REFINERY
Ras Tanura
RAISING THE STANDARD FOR COMPLEX INDUSTRIAL STRUCTURES
Project Overview
The Ras Tanura Refinery is one of Saudi Aramco's major refining assets, with the refinery supporting large-scale oil processing and downstream operations.
The project scope represented within DAR Al-Afaal's portfolio includes key industrial structures associated with the refinery environment, including flare, pipe rack and heater works.
The scale and complexity of the flare system demanded highly engineered structural solutions, with the Ras Tanura flare reaching approximately 200 metres in height and incorporating five flare risers supported by a 190-metre derrick.
- FLARE STRUCTURES
- Large-scale steel structures supporting the refinery's flare system and associated risers.
- PIPE RACKS
- Structural frameworks designed to support and route process piping across interconnected refinery facilities.
- HEATER STRUCTURES
- Steel structures supporting refinery heater systems and their associated operational requirements.
Client
Saudi Aramco Company
Location
Ras Tanura, Saudi Arabia
Sector
Oil & Gas Refining
Area
5.5 Million m²
Project IN FOCUS
A closer look at the architecture, construction, and distinctive details of Ras Tanura Flare.
